| Frame |
CF5 V carbon - Premium fibres for lightweight and performance, race geometry. Internal cable routing, 142 x12mm axle standard, flat mount rear brakes with Disc Cooler, 1 1/2" to 1 1/4" headtube. Pressfit 86.5 BB Standard, Max tyre size - 30c
|
| Fork |
Scultura CF5 Disc; full carbon; Max tyre size: 700 x 30c - Disc cooler technology
|
| Gears |
24 |
| Shifters |
Shimano Dura Ace Di2
|
| Front Derailleur |
Shimano Dura Ace Di2 |
| Rear Derailleur |
Shimano Dura Ace Di2 |
| Bottom Bracket |
SM-BB92-41B, Pressfit 86.5 |
| Chain |
Shimano CN-M9100-12 |
| Chainset |
Shimano Dura Ace; 52-36 tooth chainset; Power Meter; Crank length - 165mm (XXS), 170mm (XS), 172.5mm (S/M/L), 175mm (XL) |
| Cassette |
Shimano CS-R9200; 11-30 teeth; 12 speed |
| Brake Lever |
Shimano Dura Ace |
| Front Brake |
Shimano Dura Ace; Hydraulic disc brake caliper with Shimano CL900; 160mm rotor |
| Rear Brake |
Shimano Dura Ace; Hydraulic disc brake caliper with Shimano CL900; 160mm rotor |
| Grip |
Prologo One-Touch
|
| Handlebar |
Team SL 1P Integrated; carbon; 380mm (XXS-XS-S), 400mm (M-L-XL) |
| Stem |
Team One-Piece Integrated; carbon - Length - 90mm (XXS-XS), 100mm (S), 110mm (M-L), 120mm (XL) |
| Headset |
Merida Team SL (OP-203 neck) |
| Pedal |
Not Included |
| Saddle |
Prologo Scratch M5 with V-mount adapter; includes Merida minitool |
| Seatpost |
Merida Team SL; 27.2mm diameter; 15mm layback; Carbon; S-Flex |
| Wheel Size |
700C |
| Rims |
Part of wheelset - Vision Metron 45 SL Clincher TL Disc; 18mm inner rim width; 45 mm rim depth; carbon; Tubeless ready (tubeless tape and valves included) |
| Spokes |
Part of wheelset |
| Front Hub |
Part of wheelset - Vision Metron 45 SL Clincher TL Disc; 100 x 12mm; Centerlock |
| Rear Hub |
Part of wheelset - Vision Metron 45 SL Clincher TL Disc; 142 x 12mm; Centerlock |
| Front Tyre |
Continental Grand Prix 5000S TR; 700 x 28C; Kevlar bead; tubeless ready |
| Rear Tyre |
Continental Grand Prix 5000S TR; 700 x 28C; Kevlar bead; tubeless ready |
